Corrosion Resistance 725 Round Inconel Alloy Bar ASTM Inconel Tube Sheet

Brand Name : KAIXIN

Model Number : KX-Alloy725

Certification : ISO9001:2015

Place of Origin : China

MOQ : 200KG

Price : To negotiate

Payment Terms : T/T, L/C

Supply Ability : 50~80 TONS per MONTH

Delivery Time : 45~60days

Packaging Details : Wooden Box, size as per guests' request

Shape : Wire,Strip,Rod,Pipe,Plate

Alloy Type : Nickel-chrome-molybdenum-niobium Alloy

Raw Materials : Ni:55-59%，CR:19-22.5%，Mo:7-9.5%

Executive standard : ASTM

Delivery State : Sosoloid

Application : Used for pipe fittings, joints and bearings in acid resistant equipment. It is also widely used in Marine equipment.

Features : Corrosion resistance

Size : Negotiable

Contact Now

KX Inconel 725 Nickel Alloy Wire Round Bar Tube Steel Sheet Light Rod on Inconel Alloy

Product Description and Application



Inconel 725 is Nickel-chrome-molybdenum-niobium alloy with high corrosion resistance and age hardening to extremely high strength. It has the same corrosion resistance as Inconel 625, which is widely used in more severe corrosive environments. The strength of age hardened Inconel 725 is twice that of annealed Inconel 625. The performance of Inconel 725 is suitable for applications requiring excellent corrosion resistance and high strength. The alloy can also be used in high strength fasteners for offshore use.


Process Performance and Requirements


  • Product Fusion Process


 Vacuum Induction Furnace(VIM) and Electroslag Remelting Furnace(ESR)


  • Product Chemical Composition



Element C Si Mn P S Cr Ni Mo Ti Nb Al More
Min - - - - - 19 55 7 1 2.75 - Fe Rem
Max 0.03 0.2 0.35 0.015 0.01 22.5 59 9.5 1.7 4 0.35



  • Product Physical Property



Density 8.31g/cm3
Melting Range 1271-1343℃



  • Product Mechanical Property



Condition Heat Treatment or State

Tensile strength

MPa

Yield point

MPa

 Elongation after Breaking %

Hardness

HBW
Spar Anneal 855 427 57 Rc
Spar Age hardening 1241 917 30 36
Spar Age hardening 1241 903 31 36
Pipe Anneal 783 334 60 ---
  Age hardening 1268 921 27 39




  • Productive Process


Corrosion Resistance 725 Round Inconel Alloy Bar ASTM Inconel Tube Sheet



  • Professional Customization

Cold-drawn Wire ¢0.3~¢18mm(Delivery in rolls or trays)
Hot-Rolling Wire ¢5.5~¢20mm(Delivery in rolls)
Strip thickness 0.1~4.5*width 6~350mm(Supply in rolls or straight strips)
Smooth Forged Rod on a Lathe

¢60~350mm,L800-2500mm

Hot-rolled Burnishing ¢20~80mm,L1000-5000mm
Cold Drawn and Burnishing ¢2.5~18mm,L1000-8000mm
Seamless Tube ¢1~275mm,wall thickness 0.2~30,L1000-8000mm



Corrosion Resistance 725 Round Inconel Alloy Bar ASTM Inconel Tube Sheet
Corrosion Resistance 725 Round Inconel Alloy Bar ASTM Inconel Tube SheetCorrosion Resistance 725 Round Inconel Alloy Bar ASTM Inconel Tube SheetCorrosion Resistance 725 Round Inconel Alloy Bar ASTM Inconel Tube SheetCorrosion Resistance 725 Round Inconel Alloy Bar ASTM Inconel Tube SheetCorrosion Resistance 725 Round Inconel Alloy Bar ASTM Inconel Tube SheetCorrosion Resistance 725 Round Inconel Alloy Bar ASTM Inconel Tube Sheet
